Bench milling machine for small shop features include:
Gear-drive Spindle - for Power and Torque
Built-In Z Axis Digital Read Out - Optimum accuracy
Electric Powerfeed on X axis (Optional)
110/220V - You choose voltage for your shop
Accurate - Superior Gib Design
Rigid dovetail ways provide stability and increased accuracy
Smithy Quality is Tops:Smithy designs and builds some of the best machines. We pay attention to details, all through the process. Smithy is well-known for it's after sales service and two year warranty. Each machine is inspected twice - before it leaves the factory and before it leaves our warehouse in Ann Arbor, MI to head your way.
Heavy Duty Cast Base and Column
Over 700 lbs. of cast iron provides positive damping effect - offers greater accuracy.
Flat Dove Tail Ways
Supports more weight with better weight distribution.
Hand Scraped Ways
Another plus for greater accuracy.
Allows for adjustment to assure maximum accuracy.
Keeps hill head properly indexed to the table, assuring accuracy.
Gear Driven Spindle
No belts to change. More consistent power conversion and torque.
Easy Dual Lever Speed Adjustment
Easy to select appropriate speeds. Always works at the correct speed.
90 Degree Rotating Head
Set and indicate mill head to accurately mill at angles between 0-90 degrees.
Head Height Adjustment
Simple to move head up and down for faster machine set-up and operations.
1.5 HP 110/220V Spindle Motor
Big power and torque. Cool running 110 volt power assures longer motor life.
5” Cutting Depth on Mill Head
Good runout from min to max depth.
Bridgeport Standard R8 Collet
Industry standard cutting tools and holders are low cost and easy to use.
DRO on Z Axis
Assures accurate milling depth of cut.
Accurate Floating Dials
Calibrated in thousands. Screw pitch = 10 threads per inch.
Long Bed and Work Table
9” x 32” work table offers lots of room for complex or multiple set-ups. Three T-slots for easy fixture set-up.
Bridgeport Standard 5/8” T-Slot
Industry standard clamping/holding accessories are low cost and easy to use.
